Description

The PWRMCS-DC is a 300 watt, 48 volt DC Modular Power Supply, designed for the Xtramus MCS-2160 10 Gigabit Ethernet Managed Media Converter Chassis. It can be used as single power source, or two units can be installed to provide dual redundant power.

The PWRMCS-DC is a 300 watt rated, VIN 36-72VDC Modular Power Supply, designed for the Xtramus MCS-2160 10 Gigabit Ethernet Managed Media Converter Chassis. The Power Module is installed in either of two Power Module Bays in the rear panel of the MCS-2160 chassis. One installed PWRMCS-DC can be used as single mains power source for the MCS-2160, or two units can be installed to provide a dual redundant power supply with auto-failover from the primary to standby Power Module within a maximum of 30ms. The Power Module is a 'Hot Swap' device, suitable for field or user upgrades with no system downtime. This DC Power Module is ideal for use in industrial plants and carrier infrastructure, or any environment where the principle power source is DC.

The PWRMCS-DC has a sister Power Module, the PWRMCS-AC, which is a 300 watt rated AC, auto-ranging 90-240VAC Modular Power Supply. These two Power Modules can be used in any combination to support an MCS-2160 chassis with an AC/AC, AC/DC or DC/DC Dual Redundant Power Supply. 1x 300W AC and 1x 300W DC Power Modules supplied with MCS-2160 chassis as standard.
